Centrifugal Water Separator
Product Description
Centrifugal dewatering machine is a new type of highly efficient dewatering equipment. It adopts a screenless dewatering device, completely solving the problem of screen clogging. After being put into use, it has been highly praised by users. Through the high-speed rotation without a screen, it separates materials and water under the action of centrifugal force.
Application Areas
Civil and Light Industry
Dewatering and drying of textile (knitted) fabrics after washing
e
01
Dewatering and drying of clothes after washing
02
Dewatering and drying of printed and dyed products after washing
03
Dewatering and drying after food processing
04
Dewatering and drying of latex products after washing
05
Operation Control
Connected to medicine brewing machine, mud inlet pump and dosing pump through electric control cabinet
Can achie
ve 24 - hour continuous unmanned operation
Industrial Field
Dewatering (de - oiling) of metal parts after processes such as grinding and cutting
01
Drying, dewatering and de - oiling of hardware and electronic parts
02
Related processing of iron filings, aluminum filings and copper filings
03
Applicable to factories such as electroplating, grinding, hardware lathes and hardware fasteners
04
Equipment Characteristics of Centrifugal Water Separator
Design and Structure
Compact design
Includes devices like electric control cabinet, metering tank, flocculation mixing tank
Small floor space, light weight
01
Performance
Few faults
Low noise and vibration
Simple operation
Good at dewatering oily sludge, operates at low speed
Rotating speed of spiral shaft is about 2 - 3 rpm, low electrode consumption
02
Maintenance - related
Easy for maintenance and replacement
Not easy to block
Self - cleaning function, reducing flushing water consumption and internal circulation burden
Short daily maintenance time, simple and durable maintenance operation
Only need to replace spiral shaft and traveling ring, long service life
03
Material and Application Scope
Almost the entire body of the machine is made of stainless steel, thus extending its service life.
This equipment is suitable for dewatering treatment of both high and low concentration sludge.
When dewatering low-concentration sludge (2000mg/L and above), there is no need to build thickening tanks and sludge storage tanks, which reduces construction costs and also decreases the release of phosphorus and the generation of anaerobic odors.
04
Pre-operation preparation
Familiar with machine structure, performance and operation method.
Before starting the machine, turn the machine parts several times and check their operation.
Precautions during operation
Distribute the feed evenly to avoid excessive machine vibration due to uneven weight.
During normal operation, do not brake the opening and closing arm to prevent damage to the parts.
Do not place anything on the top cover to prevent accidents after starting.
Exception handling
If anything abnormal occurs during operation, cut off the power supply immediately.
Apply the brake.
Stop the machine and conduct a full inspection.
Basis of Material Selection
Material Types
Austenitic stainless steel (such as 321, 316L, etc.)
Haines alloy
Titanium alloy
Other corrosion - resistant materials
Selection Basis
Determine the material for parts in contact with the product according to specific user requirements.
Structure and Working Principle of Centrifugal Water Separator
Structural Composition
Drum: A high - speed rotating component
Spiral Discharger (abbreviated as Spiral): Rotates at a speed lower than the drum and is responsible for pushing solid particles
Core of Working Principle
Utilize the density difference between solid and liquid phases to achieve solid - liquid separation under the action of centrifugal force
Working Process
Drum Operation
The drum rotates at a high speed, driving the slurry inside the drum to rotate synchronously.
The slurry is subjected to centrifugal force, which is many times greater than gravity.
Particle Sedimentation
Solid particles are separated from the liquid due to centrifugal force and sediment from the axis to the inner wall of the drum.
Discharging Process
The spiral discharger rotates at a relatively low speed.
It pushes the solid particles settled on the inner wall of the drum towards the slag discharge port.
Control of Speed Difference
The speed difference between the outer drum and the spiral discharger is determined by the transmission ratio and speed of the differential.
Technical parameters
According to the physical characteristics of the material (suspension) to be separated, as well as the separation index, the size of the processing volume, the specific needs of the process and other factors, the user can scientifically select the operating parameters of the centrifuge. In this way, not only a satisfactory separation effect can be obtained, but also a good economic benefit can be achieved. In addition, in terms of color and materials, custom services are also available.
