Waste Oil Processing Centrifuge

Jinhua Shenzhou Centrifuge Co., Ltd. is one of the leading manufacturers and suppliers of waste oil processing centrifuge in China. Please feel free to wholesale customized waste oil processing centrifuge at competitive price from our factory. For more cheap products, contact us now.

Shenzhou -Decanter Centrifuge For Waste Oil Processing

Drive Type: VFD + PLC + HMI

▍ Product Description



The Waste Oil Processing decanter centrifuge is an advanced solution designed specifically for the efficient processing and treatment of waste oil.



This cutting-edge centrifuge employs state-of-the-art technology to separate impurities and contaminants from waste oil, enabling the recovery of valuable resources and promoting environmental sustainability.



▍ Equipment Characteristics

■   The centrifuge can clarify, separate and dehydrate 0.002 - 3mm materials or classify 1um-5um solid particles.

■   The differential has high precision, compact structure, stable operation and high safety.

■   The main bearing adopts imported bearing to ensure its operation accuracy and convenient operation.

■   The contact parts with materials are made of high-quality stainless steel.

■   The whole machine is equipped with a variety of safety overload protection devices to ensure safe production.

■   The whole machine system is designed with ordinary type and explosion-proof type to meet different requirements.

■   Drum cone structure with large aspect ratio, high speed and multiple angles.

■   The screw pusher adopts hard alloy material for hard surface treatment, with strong wear resistance.

■   The rack can be designed into low center of gravity, high support and mobile according to the needs of users.

■   With BD plate spiral structure, it is suitable for the concentration and dehydration of activated sludge and materials that are difficult to separate.

■   According to the actual requirements, it can be equipped with double frequency conversion and intelligent full-automatic control system.

▍ Main features

■   Continuous operation, spiral discharge, high capacity.

■   Compact structure and convenient maintenance.

■   Fully enclosed operation, clean and pollution-free on site.

■   The amount of flocculant and cleaning water is small, and the daily operation cost is low.

■   Compact equipment layout and small floor area can significantly reduce land acquisition and infrastructure investment.



Drum& Screw

304 stainless steel/duplex SS

The bowl exit is cermet







Two Motors

ABB Band or Explosion-proof motor

                       PLC Control                                                                                                                                                            SIEMENS / Schneider / ABB

Gearbox

Bearing

Big and Small Cover



▍ Process Optimization

The 3-phase decanter centrifuge can adapt to specific process requirements by:

■  Changing the bowl rotational speed to exert the best G-force for separation.

■  Adjust the scroll differential rotation to balance liquid clarity and sludge handling capacity.

■  Calibrate the pond depth to adjust liquid clarity versus solid dryness.

■  Interphase adjustment between the heavy and light liquid phases.

■  Changing the feed flow rate. These 3-phase decanters can handle a wide range of feed rates.

▍ Benefits

The benefits of 3-phase decanters include:

■  The simultaneous separation of two liquids and solids.

■  The ability to handle a wide range of solids concentrations.

■  The adjustment of the centrifuge during the process.

■  Low operating cost for high processing volume.

■  Compact size to process capacity ratio.

■  Reduced operator exposure to process fluids by sealed design.

■  Long service life due to absence of replaceable media.

▍ Technical Parameter

▍ Decanter In Oily Wastewater Treatment

Separation Effect

Can recover 80～95% of the oil.

The water content of the oil phase after separation is ≤3~5%.

The dryness of the separated residue phase is 40~60%, and the total volume is more than 80% less than before separation.

Advantage

Reusing the recovered oil as a valuable product.

Up to 90% reduced costs for transport and landfill for the separated solids.

Significant reduction in disposal costs - only about 10% of the original quantity of slurry must be dumped.

Low personnel costs because of continuous and automatic operation.

Low energy requirement.

▍ Decanter In Oil Sludge Treatment

Separation Effect

Approx. 90% of the oil contained is recovered and can be recycled as crude oil.

The water content of the oil phase after separation is ≤3~5%.

The dryness of the separated residue phase is 40~60%, and the total volume is more than 80% less than before separation.

Advantages

Approx. 90% of the oil contained is recovered and can be recycled as crude oil.

The separated solid is only approx. 10 - 20% of the original quantity of sludge. This reduces transport, landfill and incineration costs significantly.

Automatic and continuous operation saves use of personnel, even when the oil sludge has a fluctuating composition.

Elimination of the environmental hazard posed by ponds and lagoons containing oil.

▍ Customers

▍ Packing & Delivery

▍ Applications

1. Food

A flesh processing,aquatic products process and edible protein recovery;

B Extract plant protein from soybean,oily seeds and leguminous plants;

C Recovery of brewing leach liquor malt and yeast

D Treatment and recovery of wine lees liquid;

E Extract of instant coffee and tea;

F Clarification of palm oil,olive oil and seed oil;

G Extract juice from fruits ,berries and vegetables;

H Recovery of refined pectin;

I Clarification of grape juice and grape wine.

2. Environmental protection

Drilling mud ,industrial effluent ,waste water of municipal works,fertilizer,organic waste water,paint sludge,plastic

particles,gravel washing water,waste water in steel-making ,flue gas desulfurization,sewage sludge treatment of waterworks.

3. Petroleum and chemical industry

A Processing of kaolin and calcium carbonate,production of bentonite and titanium dioxide;

B Exploration of petroleum oil,natural gas,crude oil refining and related industries,additive of lube oil and waste oil recovery;

C Intermediate products and final products of organic chemistry industry;

D Thermoplastic materials,includes PVC,polypropylene,polystyrene,synthetic rubber and fiber;

E Inorganic chemical industry ,includes bleach,acid,silica products and fertilizers;

F Treatment of spent wash and molasses fermentation residues;

G Extraction of starch from wheat,corn ,cassava and potato;

H Waste liquid recovery and recycling from above industries.

Other fields

Pharmaceutical intermediates,salts and manures,etc.
